HIG-026 wcb hydraulic valve parts lost wax investment casting
- Model Number: HIG-026
- Brand Name: HIG
- Place of Origin: Shanxi, China
- Minimum Order Quantity: 10Pieces
- Supply Capacity: 200000 Pieces/month
- Payment: L/C,D/P,T/T
- MemberShip: Free Member
- Inquiry Now
HIG-026 HIG-026 wcb hydraulic valve parts lost wax investment casting Description
Material Specification
Part Material EN Spec.
Body Cast Iron A126 Class B
Ductile Iron A536 Gr.65-45-12
Disc Ductile Iron A536 Gr.65-45-12
Bronze B148 C95400
Stainless Steel 304 A351 CF-8
Stainless Steel 316 A351 CF-8M
Shaft Stainless Steel 410 A276 S410 00
Stainless Steel 431 A276 S431 00
Seat Ring EPDM /NBR
O-Ring EPDM /NBR
Bushing PTFE
Bronze B62 C83600
Valve Standard
ISO 5752/BS5155/BS EN 593/MSS SP-67/API 609
Pressure Temprature and Rating
Working Pressure 16bar/27.5bar
Testing pressure Shell: 24bar/37.5bar
Seal: 17.6bar/27.5bar
Working Temperature -20°C to 110°C EPDM Seat
-10°C to 80°C NBR Seat
Suitable Media Water, Oil& Gas
Description Products
Size DN40-DN1200
End flange ANSI B 16.1, EN 1092, AS 2129
Face to face ANSI B 16.10; EN 558-1 Series 20
Top flange ISO 5211
Related products 1. Carbon steel nipples and sockets 2. Flanges
3. Carbon steel butt-welding fittings 4. Pipes
5. High-pressure fittings 6. Valves
7. P.T.F.E .thread seal tape 8. Brass fittings
9. Ductile iron pipe fittings 10. Copper fittings
11. Grooved fittings 12. Sanitary fittings, etc.
Certificate BSI, ISO9001:2008,FM,UL
Applications Fresh water, sewage, sea water, air, vapor, food, medicine, oils, alkalis, salt etc.
Buyer's drawings or designs are available.
Package 1. Cartons without pallets.
2. Cartons with pallets.
Or as buyer's requirements.
Delivery detail
According to the quantities and specifications of each order.
Normal delivery time is from 30 to 45 days after receiving the deposit.
Material | cast iron |
---|---|
Operations | Handle lever |
Nominal Pressure | PN1.0MPa,PN1.6MPa |
Body Flange Drilling | DIN2501; ANSI Class 150 |
Face to Face | DIN3202; ANSI B 16.10 |
