Tobee Slurry Pump White Ceramic Shaft Sleeves C075J04
- Model Number: 3/2C-AH, 4/3C-AH
- Brand Name: Tobee
- Place of Origin: Hebei, China
- Minimum Order Quantity: 1
- Supply Capacity: 2000/month
- Payment: T/T
- MemberShip: Free Member
- Inquiry Now
3/2C-AH, 4/3C-AH Tobee Slurry Pump White Ceramic Shaft Sleeves C075J04 Description
Email: Sales7(at)tobeepump.com
C075-J04 Ceramic Shaft Sleeve is white ceramic for 4/3C-AH Pump and 3/2C-AH Pump.
The Shaft Sleeve spare part code is 075 and 076. We have slurry pump shaft sleeve in material 4Cr13, Ceramic coated, tungsten carbide coated and stainless steel, to meet different applications. The slurry pump shaft sleeve protects the pump shaft from slurry abrasion and corrosion, enhance the pump life time.
One of the problems of concern to operators of centrifugal slurry pumps is the wear of shaft sleeves and the deterioration of packing material in the gland.
This matter has also been under study by the Materials Research and Development Department of TOBEE PUMP for some time. The result is the development of a shaft sleeve of much superior wearing qualities.
Tobee® Slurry Pump Ceramic Shaft Sleeve, which has undergone destructive field tests for over 18 months, has proved to extend part life several times that of steel shaft sleeves on the same pump, same service. Total maintenance costs and down-time were reduced accordingly.
Slurry Pump Steel Shaft Sleeve has always been the here-to-fore accepted material for shaft sleeves for most centrifugal slurry pumps. However, steel in shaft sleeves is subject to pitting, fritting and wear that often results in short part life.
Tobee® offers part codes for ceramic shaft sleeves include: B075J04, B075J05, C075J04, C075J05, CH075J04, CH075J05, CH076J04, CH076J05, D075J04, D075J05, E075J04, E075J05, F075J04, F075J04, FAM075J04, FAM075J05, PE075J04, PE075J05, PF075J04, PF075J05, G075J04, G075G05, SH075J04, SH075J05, SH076J04,SH076J05, GH075J04, GH075G05, GH076J04, GH076J05
