Cast Iron Globe Valve

Cast Iron Globe Valve
  • Model Number: Cast Iron Globe Valve
  • Brand Name: tanghai
  • Place of Origin: tianjin, China
  • Minimum Order Quantity: 1
  • Supply Capacity: 1000/month
  • Payment: EXW/FOB/C&F/CIF
  • MemberShip: Free Member
  • Inquiry Now
  • Bookmark & Share:

Cast Iron Globe Valve Cast Iron Globe Valve Description

Cast Iron Globe Valve

Tanghai valve offers a wide variety of designed multi-turn valve configurations in stainless and carbon steel, along with virtually every special alloy required for difficult fluid compositions and high-pressure, high-temperature applications.

We provide cast and forged globe valves that are designed, engineered and manufactured in strict accordance with national piping standards.

Application:Petroleum Refineries, Chemical processing plants, Power generating plants.

Design and Manufacture Conform to MSS SP-85

Flange dimensions Conform to ANSI B16.1 CLASS125

Face to Face dimensions Conform to ANSI B16.10

Testing Conform to MSS SP-85

Sutiable Media: Water, Oil, Gas

MATERIALS OF PARTS

Number

Part Name

Material

1

Body

ASTM A126 B

2

Seating ring

Brass

3

Disc ring

Brass

4

Disc ring

ASTM A126 B

5

Locking nut

Brass

6

Stem

ASTM A276 420

7

Body gasket

08≠Steel+Graphite

8

Packing

Graphite

9

Bolts

Steel

10

Packing gland

ASTM A536 65-45-12

11

Bonnet

ASTM A126 B

12

Stem nut

Brass

13

Handwheel

ASTM A126 B

14

Bolts

Steel



SIZE

2"

2.5"

3"

4"

5"

6"

8"

10"

L

203

216

241

292

330

356

495

622

D

152

178

191

229

254

279

343

406

D1

120.7

139.7

152.4

192.5

215.9

241.3

298.5

362

D2

71.45

82.6

101.6

133.4

152.4

181

234.95

292.1

b

15.8

17.5

19.1

23.9

23.9

25.4

28.6

30.2

n-d

419

419

4-19

8-19

8-22

8-22

8-22

12-25
