DBY-25-SSFF DBY electric power diaphragm pump Description

DBY electric power double diaphragm pump

electric diaphragm pump is driven by an electric motor through a reducer, and the pump is widely used to transport various corrosive liquids, liquids with particles, high viscosity, volatile, flammable, and highly toxic liquids.

Parameters:

Flow rate: 0-20m3/h;

Lift: 30m;

Power: 0.37-4kw;

Speed: 1450r/min;

Caliber: 10-100mm;

Temperature: -15-+150 ℃;

Self suction height: 5-7m

Diaphragm pump material: cast iron, aluminum alloy, stainless steel, PTFE lining F46, rubber lining.

Diaphragm material: acrylonitrile butadiene rubber, Neoprene, fluororubber, polytetrafluoroethylene, polytetrafluoroethylene F46.

Sealing ball material: nitrile rubber, Neoprene, polytetrafluoroethylene, stainless steel, ceramic.

Material of sealing ball seat: NBR, Neoprene, fluororubber, polytetrafluoroethylene

Motors can be divided into ordinary motors, explosion-proof motors, reduction motors, and electromagnetic speed regulating motors
