Stainless Steel Ball Valve
- Model Number: SSBALL
- Brand Name: TWT
- Place of Origin: Shanghai, China
- Minimum Order Quantity: 100
- Supply Capacity: 10000/month
- Payment: T/T, D/P, L/C, Western Union
- MemberShip: Free Member
- Inquiry Now
SSBALL Stainless Steel Ball Valve Description
The TWT Stainless Steel Ball Valve has a two-piece structure that carries the full diameter design of the blowout preventer stem to reduce the fluid resistance. The stainless steel stem ensures that the operation is not affected by the side thrust generated by high pressure fluids. The T90 Stainless Steel Ball Valve, reduces parts to wear out and extends the service life. The PTFE seat can adjust the filler nut. The two-piece structure is easy to repair and can quickly carry out the repair of multiple solid bonnet after removing the valve cap assemblies PTFE seat and PTFE packing rod. The tapering PTFE filler has adjustable stop and push to prevent wear, reduce torque, and provide dual stem seal. It has an adjustable filler for self-locking cap nut, and includes protective metal fill washer.
Application | Water Industrial Usage, Industrial Usage |
---|---|
Pressure | Pn1.0 ~ 2.5MPa |
Temperature of Media | -10~450℃ |
Structure | Ball Valve |
Operation | Lever, Gear, Pneumatic, Electric, Hydraulic |
Material | Stainless Steel |
Media | Water Oil Gas etc. |
