Stainless Steel Steam Jacketing Type Tank Valve

Stainless Steel Steam Jacketing Type Tank Valve
  • Model Number: QsBFb545Y-10R DN100
  • Brand Name: QUANSHUN
  • Place of Origin: Henan, China
  • Minimum Order Quantity: 2 Sets
  • Supply Capacity: 200Sets/Week /month
  • Payment: T/T
  • MemberShip: Free Member
  • Inquiry Now
  • Bookmark & Share:

QsBFb545Y-10R DN100 Stainless Steel Steam Jacketing Type Tank Valve Description

Stainless Steel Steam Jackating Type Tank Valves  are designed to provide steam drainage and dead space free shut off for reactors, vessels, autoclaves and storage tanks. Both inside vesel opening and inside valve opening can be supplied. The steam jackating type flush bottom valve is suitable for any medium needs to keep temperature with steam ,it can prtect the medium from solidification  &  crystallization at normal temperature ,and reduce the pipe line enegy lost .


The series of stainless steel steam jackating type tank valve  has two constructions: Y-type & angle type. According to the actual operating condition, the dumping entry has two types: pipe-connecting and flat bottom. If needed ,special surface treatment on the whole valve makes the surface hardness more than HRC 60, this can ensure the sealing reliability and avoid scarring. Moreover, a rotation-resistant device is set to ensure that the valve stem only has straight line motions, and no revolving motions.  Both rising disc type (the valve is opened into tank) and lowering disc type (the valve is opened into valve) can be designed.



BENEFITS



1.This range of manual control tank bottom angle valve is manufactured in y type 45 degree integrated structure;


2. Short stroke for open/close operation;


3.lowering disc type (the valve is opened into valve) can be designed if needed.


4.The sealing surface of the valve seat and the valve disc is made of over laying cemented carbide or painted with tungsten carbide. The auxiliary line sealing guarantee the reliability of the sealing performance.


5. Crust breaking for disc rising type;


6.Disc is designed as external disc.


7.With temperature keeping function, protect the medium from solidification  &  crystallization.



TECHNICAL SPECIFICATION :


Size: DN100

Pressure: PN10

Body Material: CF8M

Connection Type:Flange



APPLICATION:

Petroleum

Metallurgy

Pharmacy

Chemical


Size DN100
Pressure PN10
Material CF8M
Connection Flange
Operating method Manual
