ZCQ-06A welding machine gas solenoid valve

ZCQ-06A welding machine gas solenoid valve
  • Model Number: ZCQ-06A
  • Brand Name: BONA
  • Place of Origin: Zhejiang, China
  • Minimum Order Quantity: 10 Piece
  • Supply Capacity: 10000 Piece/month
  • Payment: L/C,T/T,Western Union
  • MemberShip: Free Member
  • Inquiry Now
  • Bookmark & Share:

ZCQ-06A ZCQ-06A welding machine gas solenoid valve Description

2/2 way, normally close, direct action, design for use with water and air in general.

wire feeder solenoid valve


Port Size: Female 1/8”; 1/4”

Body material: Brass, Aluminum

Seal ring material: NBR

Max Media Temperature: 90℃

Voltage available: 12VAC; DC 12V; 24VAC;DC 24V; 110/120VAC;   220/230VAC

Inner Orifice: Φ2mm、Φ2.5mm、Φ3mm

work Pressure: 0-8 bar

Dimension(L×W×H): 33×33×55mm





Material Brass
Pressure Low Pressure
Temperature of Media High Temperature
Power Solenoid
Media Gas
