Zhongcheng Valve Co.,Ltd was founded in 2003, main in producing and supplying products like Knife gate valve, Ceramic valve, Ball Valve and so on, our products are selled to USA, EUROPE, THAILAND and other markets.

Knife Gate Valves With En1092 &amp

 Knife Gate Valves With En1092 &amp
  • Model Number: pz673tc-150lb
  • Brand Name: ZC
  • Place of Origin: Zhejiang, China
  • Minimum Order Quantity: 1 SET
  • Supply Capacity: 5000/month
  • Payment: T/T
  • MemberShip: Free Member
  • Inquiry Now
  • Bookmark & Share:

pz673tc-150lb Knife Gate Valves With En1092 &amp Description

Characteristice:

This valve line can replace dome valves, tuming valves. Bel valves and double-disc valves as feeding gates of storehouse pumps, or be used as an on-off for pipelines containing abrasive dry ash, water granulated slag and the like in mines. Chemical engineering and soon, Its working nominal pressure is 1.0MPa applicable temperature, applicable temperature≤200℃,and airsupply pressure 0.6-0.8MPa.

After the valve is closed, it’s fully sealed in any direction. Its body and bonnet are made of WCB steel or stainless steel casting, Its sealing surface adopts a hard serling element,

Its feed inlet is fully through without any biocks, and it has an anti -blockage blowing unit, with strong abrasion resistance, a good seal ability, a small starting load and with little ash seizure or accumulation.

It adopts a high-grade toughened structural ceramic seal. Featuring high mechanical strength, strong abrasion resistance, a long service life and a compact structure, which can be installed at any angle.

Materials for main parts


Item



Name



Material



Item



Name



Material





1



Main Body



WCB



7



Disc bracket



WCB





2



Body



WCB



8



Swing bar



WCB





3



Plate



45#+Ceramic



9



Pneumatic device





4



Seat



Ceramic



10



Stud



35CrMoVA





5



Shaft



45#



11



Nut



25




Application specification


Design and manufacture



CB/T12224





Connection end dimension



Structural length



Manufacturer’s standard





Flange dimension



JB/T 79.1





Inspection and test



GB/T 9092





Material



Carbon steel



GB/T 12229





Stainless steel



GB/T 12230





Mark



GB/T 12220





Supply



GB/T 12252
