Swing ceramic feed valve

Swing ceramic feed valve
  • Model Number: Q641TC-150LB
  • Brand Name: ZC
  • Place of Origin: Zhejiang, China
  • Minimum Order Quantity: 1 SET
  • Supply Capacity: 5000/month
  • Payment: T/T
  • MemberShip: Free Member
  • Inquiry Now
  • Bookmark & Share:

Q641TC-150LB Swing ceramic feed valve Description

Characteristice:

This valve is applicable for discharge and transportation of dry ash systmstems in power plants and storehouse pumps,or can be used as an on-off for pipelines containing abrasive dry ash. Water(such as cinder water) and the like in mines, papermaking, chemical engineering and so on, as an on-off for pipe lines with both soft grains and corrosive media, lts working nominal pressure is 1.MPa applicable temperature≤200℃, and air supply pressure 0.6-0.8MPa.

After the valve is closed, it’s fully sealed in any direction, it’s middle body adopts WCB steel casting and seamless steel pipe welding, Its sealing surface adopts a hard sealing element.

Its feed inlet is fully through without any blocks. And it has an antl-blockage blowing unit, with strong abrasion resistance. a good seal blowing unit, with strong abrasion resistance, a good seal ability, a small starting load and with little ash seizure or accumulation.

It adopts a high-grade toughened structural ceramic seal, featuring high-mechanical strength, strong abrasion resistance. a long service life and a compact structure, which can ben installes at any angle.

Materials for main parts


Item



Name



Material



Item



Name



Material





1



Body



WCB



7



Packing



Flexible Graphite





2



Plate



WCB+Composite ceramic



8



Packing gland



2Cr13





3



Seat



Composite engineering ceramic



9



Spring



50CrVA





4



Plate seat



45#



10



Pneumatic device





5



Stem



2Cr13



11



Nut



25





6



Middle body



WCB



12



Stud



35CrMoVA




Application specification


Design and manufacture



CB/T12224





Connection end dimension



Structural length



Manufacturer’s standard





Flange dimension



JB/T 79.1





Inspection and test



GB/T 9092





Material



Carbon steel



GB/T 12229





Stainless steel



GB/T 12230





Mark



GB/T 12220





Supply



GB/T 12252
