Ceramic butterfly Valve

Ceramic butterfly Valve
  • Model Number: BZ644TC-150LB
  • Brand Name: ZC
  • Place of Origin: Zhejiang, China
  • Minimum Order Quantity: 1 SET
  • Supply Capacity: 5000/month
  • Payment: T/T
  • MemberShip: Free Member
  • Inquiry Now
  • Bookmark & Share:

BZ644TC-150LB Ceramic butterfly Valve Description

Characteristics

The ceramic butterfly  valve adopts hi-tech and new ceramic structure materials to make its sealing elements and wearing parts ,thus improving its resistance to abrasion and corrosion and airtightness ,and extending its service life greatly . It is mainly applied in such industrial fields as power ,petroleum chemical engineering ,metallurgy mining and sewage treatment . especially for such harsh working conditions as high abrasion ,strong corrosion and high temperature and pressure

Material for main parts


Item



Name



Material



Item



Name



Material





1



Body



WCB



9



Packing



304+Graphite





2



Seat Plate



25#



10



Packing bushing



1Cr13





3



Bushing



PTFE



11



Packing Gland



WCB





4



SEAT



Ind Ceramic



12



Yoke



Q235





5



Sealing Plate



25#



13



Worm





6



Sealing Ring



Ind Ceramic



14



Stud



B7





7



Disc



WCB+Ind Ceramic



15



Nut



2H





8



Stem



2Cr13




Application Specification


Design & Manuafcture



JB /T8691





Connection end dimension



Face to face



GB/T 15188.2





Flange dimension



JB/T 79.1





Inspect & Test



JB/T 8691





Material



Carbon Steel



GB/T 12229





Stainless Steel



GB/T12230





Mark



GB/T12220





Supply



GB/T12252
