Electric Ceramic Scum Valve

Electric Ceramic Scum Valve
  • Model Number: Q41TC
  • Brand Name: ZC
  • Place of Origin: Zhejiang, China
  • Minimum Order Quantity: 1 SET
  • Supply Capacity: 5000/month
  • Payment: T/T
  • MemberShip: Free Member
  • Inquiry Now
  • Bookmark & Share:

Q41TC Electric Ceramic Scum Valve Description

Characteristics

This valve is applicable for high-hardness grains or corrosive hydraulic coal transportation ,hydraulic des lagging and cinder removal and slurry transportation pipelines with the working medium being slag water ration>1:5 and the biggest grain≤5mm .its working nominal pressure is (1.0 1.6, 2.5 ,and 4.0Map ) and applicable temperature≤100℃ 。

All medium contacting parts are made of structural ceramic with extremely high chemical stability and hardness , there for it has extremely strong resistance to abrasion ,corrosion and erosion ,good heat insulation and small thermal expansion .its feed inlet is fully through without any blocks and it has an anti-blockage blowing until with strong abrasion resistance  ,a good sealing ability ,a small starting load and little ash seizure or accumulation.

 It adopts a high –grade toughened structural ceramic seal , featuring high mechanical streagth ,strong abrasion resistance ,a long service life and a compact structure ,which can be installed at any angle

Material for main Parts


Item



Name



Material



Item



Name



Material





1



Body



WCB



6



Stud



35#





2



Main Body



WCB



7



Packing



Fexible Graphite





3



Seat



Ind ceramic



8



Packing Gland



2Cr13





4



Disc



WCB+ind Ceramic



9



Stem



1Cr13





5



Nut



25#



10



Electric



Assembly




Application Specification


Design & Manufacture



GB/ T12224





Connection end dimension



Face to face



Manufacture’s Standard





Flange dimension



Gb/T9113.1





Inspect & Test



JB/T 9092





Material



Carbon Steel



GB/T 12229





Stainless Steel



GB/T12230





Mark



GB/T12220





Supply



GB/T12252
