Pneumatic ceramic feed valve

Pneumatic ceramic feed valve
  • Model Number: WZ644TC-150LB
  • Brand Name: ZC
  • Place of Origin: Zhejiang, China
  • Minimum Order Quantity: 1 SET
  • Supply Capacity: 5000/month
  • Payment: T/T
  • MemberShip: Free Member
  • Inquiry Now
  • Bookmark & Share:

WZ644TC-150LB Pneumatic ceramic feed valve Description

Characteristice:


This valve is applicable for discharge and transportation of dry ash systems in power plants and storehouse pump, or can be used as an on-off for pipelines containing abrasive dry ash, water(such as cinder water) and the like in mines. Papermaking, chemical engineering and so on, Its working nominal pressureis 1.0MPa, applicable temperature≤200℃,and airsupply pressure 0.6-0.8MPa.

After the valve is closed, it’s fully sealed in any direction. Its middle body adopts WCB steel casting and seamless steel pipe welding, Its sealing surface adopts a hard sealing element.

Its feed inlet is fully through without any biocks, and it has an anti blockage blowing unit, with strong abrasion resistance, a good seal ability, a small starting load and with little ash seizure or accumulation.

It adopts a high-grade toughened structural ceramic seal. Featuring high mechanical strength, strong abrasion resistance, a long service life and a compact structure, which can be installed at any angle.

Materials for main parts


Item



Name



Material



Item



Name



Material





1



Body



WCB



7



Middle body



WCB





2



Plate



Composite engineering ceramic



8



Packing



Flexible Graphite





3



Seat



Composite engineering ceramic



9



Packing gland



2Cr13





4



Stem



2Cr13



10



Bracket



Q235





5



Stud



35CrMoVA



11



Pneumatic device





6



Nut



25




Application specification


Design and manufacture



CB/T12224





Connection end dimension



Structural length



Manufacturer’s standard





Flange dimension



JB/T 79.1





Inspection and test



GB/T 9092





Material



Carbon steel



GB/T 12229





Stainless steel



GB/T 12230





Mark



GB/T 12220





Supply



GB/T 12252
