Electric Hydraulic thin ceramic gate valve

Electric Hydraulic thin ceramic gate valve
  • Model Number: PZ273TC-150LB
  • Brand Name: ZC
  • Place of Origin: Zhejiang, China
  • Minimum Order Quantity: 1 SET
  • Supply Capacity: 5000/month
  • Payment: T/T
  • MemberShip: Free Member
  • Inquiry Now
  • Bookmark & Share:

PZ273TC-150LB Electric Hydraulic thin ceramic gate valve Description

Characteristics

This valve is application as an on-off media containing high –hardness grains ,such as cinder water , or for pipelines with both soft grains and corrosive media .its nominal pressure is 1.0 Mpa ,and application temperature≤150℃ 。the sealing surface adopts had seal , and all medium contacting parts are made of structural ceramic withextremely high chemical stability and hardness .Therefor , it has extremely strong resistance to abrasion ,corrosion and erosion .good heat insulation and small thermal expansion . Its feed inlet is fully through without any blocks and it has strong abrasion resistance a good seal ability and a small strating load , with little ash seizure or accumulation .It adopts a high-grace toughened structural ceramic seal ,featuring high mechanical  strength  ,strong abrasion resistance ,a long service life and a compact structure which can be installed at any angle

Material for main Parts


Item



Name



Material



Item



Name



Material





1



Body



WCB



7



Stem



Q235+Hcr





2



Disc



Ind+Ceramic



8



Yoke



Q235





3



Seat



Ind Ceramic



9



Gasket



10





4



Adjusting Screw



35#



10



Nut



25





5



Packing



PTFE



11



Electric



Assemble





6



Packing Gland



WCB




Application Specification


Design & Manuafcture



GB/ T 8691





Connection end dimension



Face to face



GB/T 15188.2





Flange dimension



Gb/T9113.1





Inspect & Test



JB/T 8691





Material



Carbon Steel



GB/T 12229





Stainless Steel



GB/T12230





Mark



GB/T12220





Supply



GB/T12252
