Zhongcheng Valve Co.,Ltd was founded in 2003, main in producing and supplying products like Knife gate valve, Ceramic valve, Ball Valve and so on, our products are selled to USA, EUROPE, THAILAND and other markets.

Moving sealing knife gate valve

Moving sealing knife gate valve
  • Model Number: PZ673X 4”-24”
  • Brand Name: ZC
  • Place of Origin: Zhejiang, China
  • Minimum Order Quantity: 1 SET
  • Supply Capacity: 5000/month
  • Payment: T/T
  • MemberShip: Free Member
  • Inquiry Now
  • Bookmark & Share:

PZ673X 4”-24” Moving sealing knife gate valve Description

Moving sealing knife gate valve

Model:PZ673X 4”-24”

Solid One Piece Cast Body, Replacement seat,  rising stem,
Designed & Tested to MFS

Operated type: Pneumatic

MATERIALS OF CONSTRUCTION

Body:Carbon steel , Stainless steel and special material
Knife:SS304 as standard,,SS316 for option
Seat: EPDM ,NBR ,PTFE

COMMON APPLICATIONS

• Waste Water and Water
• Pulp & Paper
• Food
• Fly Ash Handling
• Sewage

Product Specification

Moving -Sealing knife gate valve internal structure more closely, disc and seal tightly stick, achieve better sealing effect.

Sealing ring and seat is one-piece  structure so that the can't fall off while opening /closing

The sealing ring  could replace in the case of opening  valve , greatly improve the service efficiency of knife gate valve

Products are widely used in paper making, sugar, mining, metallurgy, chemical industry, electric power, water treatment, etc.
