Pneumatic Through Conduit knife gate valve

Pneumatic Through Conduit knife gate valve
  • Model Number: SCZ73X/H 4””-24””
  • Brand Name: ZC
  • Place of Origin: Zhejiang, China
  • Minimum Order Quantity: 1 SET
  • Supply Capacity: 5000/month
  • Payment: T/T
  • MemberShip: Free Member
  • Inquiry Now
  • Bookmark & Share:

SCZ73X/H 4””-24”” Pneumatic Through Conduit knife gate valve Description

PRODUCT DETAILS:

Model:SCZ73X/H 4””-24””

Solid One Piece Cast Body, welded body
Designed & Tested to MSS SP81

Connection :Wafer Type , Flange Type

Operated type: Pneumatic


MATERIALS OF CONSTRUCTION

Body: Carbon steel , Stainless Steel(Solid solution treatment), Special material
Seat: EPDM, NBR, METAL


Specification

Bi-direcational sealing , the gate is longer and the bottom extends out of the body and requires two packing gland The gate forms a cavernous port whose role is that when the gate opens ,medium may flow away completely without any detention ;

The seat keeps sealing in the condition of high concentration of medium , there is nothe medium accumulation in the bellow of knife as no the stagnant zone Product are widely used in paper making , chemical industry and  sugar ,etc
